AudioCodes Mediant Series User Manual

Quick Setup Guide 2. Installing the Hardware
BroadCloud SIP Trunk 5 AudioCodes Mediant BRI/PRI Gateway
2 Installing the Hardware
2.1 Mediant 500L Media Gateway
2.1.1 Front Panel
LEDs on the front panel indicate functionality statuses.
Figure 2-1: Front Panel - LEDs
When green, 1 (power LED) indicates power is on. Table 2-1 describes 2 (Status LED).
Table 2-1: Status LED
LED
Color
LED State Description
Green On Device is operational.
Flashing Initial rebooting stage.
Red On Boot failure.
- Off Advanced rebooting stage.
2.1.2 Rear Panel
Figure 2-2: Rear Panel
Table 2-2: Rear Panel
Item # Label Description
1 POWER 12V -- 3A AC power supply plug entry to connect to the external AC power supply adapter.
2 ON / OFF Power button which powers on the device when pressed in and powers off the device when
pressed again (pressed out).
3 CONSOLE RJ-45 port for RS-232 serial communication with the device.
