Mediant 1000 Digital
Fast Track Guide 22 Document #: LTRT-63802
6. Select the coder (i.e., vocoder) that best suits your VoIP system requirements. The default
coder is: G.723.1 30 msec. To program the entire list of coders you want the Mediant 1000
to use, refer to the digital Mediant 1000 User’s Manual.
7. Map outgoing calls to IP addresses (when Proxy isn’t used) by completing these steps:
• Click the arrow button next to the ‘Tel to IP Routing Table’ label; the ‘Tel to IP Routing’
screen opens.
Any telephone number whose destination number matches the prefix defined in the
‘Destination Phone Prefix’ field and whose source number matches the prefix defined in
the adjacent ‘Source Phone Prefix‘ field, is sent to the IP address entered in the ‘IP
Address’ field.
• Click the Submit button; the ‘Tel to IP Routing’ table is automatically updated.
• Click Quick Setup; you’re returned to the ‘Quick Setup’ screen.
8. For more information on the ‘Tel to IP Routing’ table refer to the SIP digital Mediant 1000
User’s Manual.
9. Enable E1/T1 B-channels by completing these steps:
• Click the arrow button next to the ‘Trunk Group Table’ label; the ‘Trunk Group Table’
screen opens.
• Select the number of the trunk you want to enable from the ‘Trunk ID’ drop-down list.
• Enter the number of B-channels you want to enable in the ‘Channels’ field.
• Enter the starting phone number in the adjacent ‘Phone Number’ field (these are virtual
numbers, used only to define enabled B-channels).
• Click the Submit button; the ‘Trunk Group Table’ table is automatically updated.
• Click Quick Setup; you’re returned to the ‘Quick Setup’ screen.
10. Click the Reset button and click OK in the prompt; the Mediant 1000 applies the changes
and restarts.
11. After the gateway is reset, configure the Mediant 1000 trunk parameters. For information on
configuring the trunk parameters, refer to Section
3.5 on page 23.
Note: SIP users should continue with Section 3.5 on page 23.
