REMOTE CONTROL OPERATION
20. NEXT ( )/DOWN
Press to navigate in a down direction
when menu is displayed on the screen.
21. STOP ( )
22. PAUSE ( )
23. ZOOM
24. OSD
25. SOURCE
26. VOL+/VOL-
Press to skip to the next chapter/track.
Press once to pause a playback, then
press Play ( ) to continue playback.
Press twice to stop playback.
Press repeatedly to display title
elapsed time, title remaining time,
chapter elapsed time or chapter
remaining time, or hide the display.
Press repeatedly to switch to available
USB or SD/MMC/MS CARD signal
sources, or to return to the DVD mode.
Press to temporarily pause playback;
press it again or press Play ( ) to
resume playback.
Press VOL+ to increase the
volume. Press VOL- to decrease the
volume.
Press to zoom in/out of a scene. The
available zoom ratios are 2X, 3X, 4X,
1/2, 1/3, and 1/4. In zoomed-in mode,
the direction keys can be used to move
the zooming center.
Applies to DVD, VCD, etc.Note:
-14-
21
20
22
23
24
25
26
FUNCTION

Audiovox DS9343TPK Specifications

General

Compatible DISC	DVD/VCD/CD/MP3
Signal system	PAL/NTSC
Laser	Semiconductor laser, Wave length: 650 nm/795nm
Panel size	9 inch
Frequency response	20Hz to 20KHz
Audio output	1.2 V ( 0.2V) RMS/10 kOhm
Video output	1 Vp-p 75 Ohm unbalanced
Dynamic range	≥85dB
Power source	DC 9-12V
Power consumption	10W
Operating temperature	0~35 C
Battery Type	Li Polymer
