CONNECTING TO A TV
-15-
Use an AV cable (not supplied) to
connect the AV OUT jack to the video
input terminal, L/R channel audio input
terminals of a TV.
After the connection has been correctly
made, turn on the connected TV and set
it to AV mode. You can then view the
video with the connected TV.
Yellow WhiteRed
RL
VIDEO
Input
AUDIO
Input
TV
OFF/ONAV O UTPHONE
This player has an AV OUT jack. You can connect it to a TV for viewing.

Audiovox DS9343TPK Specifications

General

Compatible DISC	DVD/VCD/CD/MP3
Signal system	PAL/NTSC
Laser	Semiconductor laser, Wave length: 650 nm/795nm
Panel size	9 inch
Frequency response	20Hz to 20KHz
Audio output	1.2 V ( 0.2V) RMS/10 kOhm
Video output	1 Vp-p 75 Ohm unbalanced
Dynamic range	≥85dB
Power source	DC 9-12V
Power consumption	10W
Operating temperature	0~35 C
Battery Type	Li Polymer
