128-7194
10 of 20
e. If the outside air temperature is cold, it may
be beneficial to warm the adhesive backing
on the base using a portable hair dryer, or
by holding the backing surface in front of a
vehicle heater vent.
f. Remove the plastic liner from the adhesive
backing on the base, and fix the base in
position on the surface; make sure the
mounting pad is accurately positioned on
the first try, since repositioning may be
difficult, if not impossible.
g. If the mount is to be screwed in place, do
not remove the plastic liner from the
adhesive backing. Use appropriate sheet
metal or machine screws for this purpose.
-10-
MOUNTING
PLATE
PLASTIC LINER
AND ADHESIVE
BACKING
MOUNTING
BASE
ASSEMBLY
SCREW HOLES
(4) FOR DIRECT
HARD MOUNTING
BASE
ASSEMBLY
MOUNTING
PLATE
