6
LR 435
ITALIANO
DATI TECNICI
ALIMENTAZIONE 11 - 15 VDC
ASSORBIMENTO A VUOTO 0.8 A
ASSORB. MAX CONT. (4 Ch x 4 Ohm) 4 x 20 A
ASSORB. MAX IMPULSIVO 35 A
DISTORSIONE THD (1KHz) 0.07 %
POTENZA OUT CONT. (4 Ch x 4 Ohm) 4 x 35 W (RMS)
POTENZA OUT CONT. (4 Ch x 2 Ohm) 4 x 50 W (RMS)
POTENZA OUT MONO (2 Ch x 4 Ohm) 2 x 100 W (RMS)
POTENZA OUT CONT. (3 Ch x 4 Ohm) 35 + 35 + 100 W
BANDA PASSANTE (-3 dB) 4 Hz - 70 KHz
BANDA FREQUENZA DI CROSSOVER (LR 435 XR ) 40 - 220 Hz
PENDENZA FILTRI (LR 435 XR) 12 dB/Ott.
FATTORE DI SMORZAMENTO 120
TEMPO DI SALITA 4.5 uS
RAPPORTO S/N PESATO A 98 dB
SENSIBILITA' D'INGRESSO 0,15 V - 1,5 V
IMPEDENZA D'INGRESSO 15 KOhm
IMPEDENZA D'USCITA SINGOLO CANALE 2 - 4 - 8 Ohm
IMPEDENZA D'USCITA MONO (BRIDGE) 4 - 8 Ohm
REMOTE IN 3 - 16 VDC
REMOTE OUT 12 VDC
MUTE IN 3 - 16 VDC
MUTE OUT 12 VDC
DIMENSIONI (BxAxL) 170 x 50 x 290 mm
PESO 2,300 Kg
ENGLISH
TECHNICAL DATA
POWER SUPPLY 11 - 15 VDC
IDLING CURRENT 0.8 A
MAX CONSUMPTION (4 Ch x 4 Ohms) 4 x 20 A
MAX IMPULSIVE CONSUMPTION 35 A
DISTORTION THD (1 KHz) 0.07 %
OUT POWER CONT. (4 Ch x 4 Ohms) 4 x 35 W (RMS)
OUT POWER CONT. (4 Ch x 2 Ohms) 4 x 50 W (RMS)
OUT POWER MONO (2 Ch x 4 Ohms) 2 x 100 W (RMS)
OUT POWER CONT. (3 Ch x 4 Ohms) 35 + 35 + 100 W
BANDWIDTH (-3 dB) 4 Hz - 70 KHz
CROSSOVER FREQUENCY (LR 435 XR) 40 - 220 Hz
FILTERS SLOPE (LR 435 XR) 12 dB/Oct.
DAMPING FACTOR 120
RISE TIME 4.5 uS
S/N RATIO (W "A") 98 dB
INPUT SENSITIVITY 0.15 V - 1.5 V
INPUT IMPEDANCE 15 KOhms
OUTPUT IMPEDANCE EACH CHANNEL 2 - 4 - 8 Ohms
OUTPUT IMPEDANCE MONO (BRIDGE) 4 - 8 Ohm
REMOTE IN 3 - 16 VDC
REMOTE OUT 12 VDC
MUTE IN 3 - 16 VDC
MUTE OUT 12 VDC
SIZE (WxHxD) 175 x 50 x 290 mm (6.89 x 1.97 x 11.42 inch)
WEIGHT 2.300 Kg (5.07 lbs)
