Audison LRx 4.1k User Manual

6463
The Universal Sound
Owner’s manual
Push
to click
MAX ø6,5 mm
1
2
43
35
You can connect the cables to ECI-H module
before securing it to the amplifier.
Choose the module position and follow
the connection instructions you can find on
the labels. The amplifier must be off.
Flush mounting Semi-embedded mounting
How to run the cables under the amplifier
If you use CONNECTION Audison interconnects, attach Y BLOCK on one of the mounting
pins of the amplifier after plugging in RCA connectors.
Route the cable in the proper location and secure it with the supplied clips.
To attach the clip, insert the tongue first, and then press until you hear a click.
CONNECTION Audison Y BLOCK
Perimetro esterno
External Outline
Perimetro per il montaggio semi-incassato
Semi-Projecting Outline
Input Cable
Hole Area
Perimetro per il montaggio a filo del pannello
Non-Projecting Outline
Mounting template
A template is supplied to help you pre-plan the mounting of your amplifier. Printed on the
template are instructions for flush or semi-embedded mounting, or for installing it on a flat
surface. If you want to hide the cables, you can refer to the proper holes on the template.
LRx 4.5
LRx 4.1k

Audison LRx 4.1k Specifications

General

Brand	Audison
Model	LRx 4.1k
Category	Car Amplifier
Language	English
