3. Transport, storage and packaging
3.1. Transport
For transport to place of installation, use sturdy packaging.
Hovering load!
Death or serious injury possible.
→
Do NOT stand below hovering load.
→
Linear thrust units mounted to a valve in combination with an actuator: Attach
ropes or hooks for the purpose of lifting by hoist to valve and NOT to actuator.
→
Respect total weight of combination (gearbox, linear thrust unit, actuator, ...).
Table 1: Weights linear thrust units
Base weight [kg]Weight [kg]
2)
Stroke
1)
Type
1)
11850LE 12.1/ LE 25.1
9100
9125
10200
11250
13400
14500
111063LE 50.1
12125
15250
18400
402380LE 70.1 / LE 100.1
26160
32320
35400
4045100LE 200.1
50200
62400
68500
Refer to name plate1)
Without actuator and base2)
3.2. Storage
Danger of corrosion due to inappropriate storage!
→
Store in a well-ventilated, dry room (maximum humidity 70 %).
→
Protect against floor dampness by storage on a shelf or on a wooden pallet.
→
Cover to protect against dust and dirt.
→
Apply suitable corrosion protection agent to uncoated surfaces.
Long-term storage
If the device must be stored for a long period (more than 6 months) the following
points must be observed in addition:
1. Prior to storage:
Protect uncoated surfaces, in particular the output drive parts and mounting
surface, with long-term corrosion protection agent.
2. At an interval of approx. 6 months:
Check for corrosion. If first signs of corrosion show, apply new corrosion protec-
tion.
8
LE 12.1 – LE 200.1
Transport, storage and packaging
