Information: Please state type and commission no. of the device (see name plate) when ordering spare parts.
Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts
AUMA from any liability. Delivered spare parts may slightly vary from the representation in these instructions.
TypeDesignationNo.TypeDesignationNo.
Sub-assemblyMechanical position indicator553.0Sub-assemblyHousing001.0
Sub-assemblySocket carrier with motor cable har-
ness
554.0Sub-assemblyHollow shaft with worm wheel003.0
Sub-assemblyPotentiometer for position transmitter556.0Sub-assemblyDrive shaft005.0
Sub-assemblyPotentiometer without slip clutch556.1Motor coupling on output drive shaft005.1
Sub-assemblyHeater557.0Manual drive coupling005.3
Sub-assemblyBlinker transmitter including pins at
wires (without impulse disc and insula-
tion plate)
558.0Worm wheel006.0
Sub-assemblyControl unit with torque switching
heads and switches
559.0–1Sub-assemblyPlanetary gearing for manual drive009.0
Sub-assemblyControl unit with magnetic limit and
torque transmitter (MWG) for Non-in-
trusive version in combination with
AUMATIC integral controls
559.0–2Sub-assemblyTorque lever017.0
Sub-assemblySwitch stack for direction OPEN560.0–1Gear segment018.0
Sub-assemblySwitch stack for direction CLOSE560.0–2Crown wheel019.0
Sub-assemblySwitch for limit/torque560.1Sub-assemblyDrive pinion II for torque switching022.0
Switch case560.2Sub-assemblyOutput drive wheel for limit switching023.0
Sub-assemblyPosition transmitter RWG566.0Sub-assemblyDrive wheel for limit switching024.0
Sub-assemblyPotentiometer for RWG without slip
clutch
566.1Sub-assemblyLocking plate025.0
Sub-assemblyElectronic board RWG566.2Sub-assemblyWire for protective earth (pin)058.0
Sub-assemblyWire harness for RWG566.3Sub-assemblyMotor (VD motor incl. no. 079.0)070.0
Sub-assemblySlip clutch for potentiometer/RWG567.1Sub-assemblyPlanetary gearing for motor drive
(SQ/SQR 05.2 – 14.2 for VD motor)
079.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblyReduction gearing155.0
Pin for motor coupling583.1Sub-assemblyCover for switch compartment500.0
Sub-assemblyRetaining spring for motor coupling584.0Sub-assemblySocket carrier (complete with sockets)501.0
Sub-assemblyOutput drive flange with end stop596.0Sub-assemblyPin carrier without pins502.0
SetSeal kit, smallS1Sub-assemblySocket for control503.0
SetSeal kit, largeS2Sub-assemblySocket for motor504.0
Sub-assemblyPin for controls505.0
Sub-assemblyPin for motor506.0
Sub-assemblyPlug cover507.0
Sub-assemblyCoupling525.0
Sub-assemblyScrew plug539.0
Sub-assemblyHandwheel with ball handle542.0
64
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2 Control unit: electronic (MWG)
Spare parts AC 01.2 Non-Intrusive
