Standard:
6 programmable output contacts:
●
5 potential-free NO contacts with one common, max. 250 V AC, 1 A (resistive load)
-
Default configuration: End position CLOSED, end position OPEN, selector switch in
REMOTE, torque fault CLOSE, torque fault OPEN
●
1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
-
Default configuration: Collective fault signal (torque fault, phase failure, motor protection
tripped)
Options:
6 programmable output contacts:
●
5 change-over contacts with one common, max. 250 V AC, 5 A (resistive load)
●
1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
12 programmable output contacts:
4)
●
10 potential-free NO contacts, one common for respectively 5 contacts, max. 250 V AC,
1 A (resistive load)
●
2 potential-free change-over contacts, max. 250 V AC, 5 A (resistive load)
6 programmable output contacts:
●
6 potential-free change-over contacts without one common, per contact max. 250 V AC,
5 A (resistive load)
10 programmable output contacts:
4)
●
10 potential-free change-over contacts without one common, per contact max. 250 V
AC, 5 A (resistive load)
All output signals must be supplied with the same potential.
Status signals
Galvanically isolated analogue output E2 = 0/4 – 20 mA (load max. 500 Ω)
Position feedback signal
Standard:
Auxiliary voltage 24 V DC, max. 100 mA for supply of the control inputs, galvanically isolated
from internal voltage supply
Option:
Auxiliary voltage 115 V AC, max. 30 mA to supply the control inputs
5)
, galvanically isolated
from internal voltage supply
Voltage output
Standard:
●
Selector switch LOCAL - OFF - REMOTE (lockable in all three positions)
●
Push buttons OPEN, STOP, CLOSE, RESET
●
6 indication lights:
-
End position CLOSED (yellow), torque fault CLOSE (red), motor protection tripped
(red), torque fault OPEN (red), end position and running indication OPEN (green),
Bluetooth (blue)
●
Graphic LC display, illuminated
Options:
●
Special colours for the 5 indication lights:
-
End position CLOSED (green), torque fault CLOSE (blue), torque fault OPEN (yellow),
motor protection tripped (white), end position OPEN (red)
Local controls
Bluetooth class II chip, version 2.0 with a range up to 10 m in industrial environments. Supports
the SPP Bluetooth profile (Serial Port Profile).
Programming software:
AUMA CDT, commissioning and diagnostic tool for windows based PCs, PDAs and smart
phones
Bluetooth
Communication interface
