18
EN
CONNECTION DIAGRAM
Important notes
• Make sure that the speaker impedance is at least 4 ohms. Otherwise,
the speakers may be damaged.
• Be careful not to let the bare ends of the speaker wires touch each
other, or come in contact with other metal objects. Doing so may
damage the speakers.
• Observe the indicated polarity on the amplier and speaker wires.
Connect +/+ and -/-. Otherwise, the sound result will be unnatural.
Connecting External Audio Equipment
To Next Page
