Subwoofer:
Sub-W output - enable/disable subwoofer.
Sub-W level - adjusting the subwoofer volume level.
Sub-W stereo - operating mode 7/8 RCA subwoofer outputs (Mono/Stereo).
Fader
Adjusting the relative volume between 1/2 and 3/4 channels.
Balance
Adjusting the relative volume between left and right channels.
Volume Step
Selecting the volume control step value (1/2/3).
Volume limit
Selecting the maximum possible volume level (3 - 62).
Power on vol.
Selecting the volume level when turning on the receiver (1 - 62).
X-Over
10
1/2 Channel - setting high-pass filter (HPF), low-pass filter (LPF), filter type,
slope, level and phase of 1/2 channels.
1/2-HPF FRQ - сutoff frequency: THROUGH (off)/20 Hz - 12.5 kHz.
1/2-HPF TYPE - filter type.
1/2-HPF SLOPE - slope: 6 - 48 dB per octave.
1/2-LPF FRQ - сutoff frequency: THROUGH (off)/20 Hz - 12.5 kHz.
1/2-LPF TYPE - filter type.
1/2-LPF SLOPE - slope: 6 - 48 dB per octave.
1/2 GAIN - level 1/2 channels, from -8 dB to 0 dB.
1/2 PHASE - Electrical phase switching:0° / 180°
3/4 Channel - setting high-pass filter (HPF), low-pass filter (LPF), filter type,
slope, level and phase of 3/4 channels.
3/4 -HPF FRQ - сutoff frequency: THROUGH (off)/20 Hz - 12.5 kHz.
3/4 -HPF TYPE - filter type.
3/4 -HPF SLOPE - slope: 6 - 48 dB per octave.
EQ SETTING
