18 US-EN
Temperature station
Note: Before mounting the temperature sta-
tion, please remove the stand
26
by simply
pulling it off.
Mark the location of the hole (D 0.3 in /
7.7 mm) on the wall.
Note: Use the included drilling template
intended for marking the drill holes.
Drill the hole with an electric drill.
Push the wall anchor
28
into the drilled
hole.
Using a crosshead screwdriver, screw the
screw
27
into the wall anchor.
Hang the temperature station by placing
the hanging slot
22
on the screw.
0.125in / 0.3mm
0.125 in/3 mm
Outdoor sensor
Mark the location of the hole (D 0.3 in /
7.7 mm) on the wall.
Note: Use the included drilling template
intended for marking the drill holes.
