7
Step 5
Install Cooking Grid
If Warming Rack is installed, remove legs from holes
in sides of the firebowl as instructed in “Unpacking”
on page 4. Place the back edge of the Cooking Grid
on the ledges of the firebowl ends and slide towards
the back of the back of the grill until the Cooking
Grid drops down into a flat position with all four sides
resting on the firebowl ledges.
Drip Tray Access
The Drip Tray is accessed for cleaning by
rotating the spring tab and sliding the tray out
from under the grill.
To reduce the risk of serious injury or death from fire or explosion:
• Be sure the grill has cooled completely before removing the drip tray.
• Be sure to empty and re-install the drip tray after each use.
WARNING
!
To reduce the risk of a laceration hazard, wear protective gloves when handling parts that have sharp edges.
CAUTION
!
Note:
Shown without Igniter
Housing for clarity
Spring Tab
Drip Tray
