5.Operating
5.1 Working Mode
The working modes of the inverter include-start mode, run mode, and standby mode. In each working
mode, the LCD displays corresponding information.
Startup mode
The start mode means that the light conditions meet the DC start conditions of the inverter, but the grid
has not yet been connected to power generation. In this mode, the inverter information is displayed in
sequence. After the display is completed, the inverter meets the grid-connected conditions and switches
from the startup mode to the running mode, otherwise, it switches to the standby mode.
The screen display sequence of the startup mode is shown in Figure 5-1(take AU 50K3P as an example).
The data in the following tables and graphs are only sample data, and take AU 60K3P as an
example, the actual display content and data may change.
