35
Fig 5-1 Start interface
ā Running mode
In the Running mode, the inverter converts the DC power of the PV arrays into AC power and integrates it
into the grid. At the same time, the inverter always outputs the maximum energy in the maximum power
point tracking (MPPT) mode.
In running mode, the LCD refreshes the contents every two seconds, so the contents are only valid for the
current two seconds.The LCD displays the default information. After 30 seconds, the LCD displays the
default information, as shown in Figure 5-2. After 10s-20s, the display enters the low-power state.Tap
again to wake up the backlight.
Fig 5-2 Default interface of running mode
After the PV arrays voltage> 300V, the system will count down for 20 seconds. Within 20 seconds,
the PV array voltage will always meet the grid-connected power generation requirements before it
will switch to the operation mode.
Power :60000W
Today's power generation 30.5kwh
To Next Page
