In running mode, the screen display content is shown in Table5-3 (take AU 50K3P as an example)
Fig 5-3 Normal interface of running mode
Note:
1. Under grid-connected conditions, tap the position of the indicator of the sound control switch, and the
background indicator of the LCD screen will light up. If you do not operate the LCD any more, the
background indicator will turn off after 20 seconds, and the LCD screen will restore the default time
display.
Power :40000W
Today's power 30.5kwh
Total power generation
90000 Kwh
DC voltage1: 300V
DC current 1: 10.2A
DC voltage2: 300V
DC current 2: 10.2A
DC voltage3: 300V
DC current 3: 10.2A
A Phase voltage: 230V
A phase current: 10.2A
C Phase voltage: 230V
C phase current: 10.2A
Mains frequency: 50Hz
Real-time temperature: 30℃
Daily power generation time
11:30:40
B Phase voltage: 230V
B phase current: 10.2A
To Next Page
