The REMOTE SETUP procedure is used to modify one proportional output at a
time. The procedure will not be performed if the actuators corresponding to the
other proportional outputs are not in the rest position.
If necessary, it is possible to restore factory settings at any time (see paragraph 6.4).
6.1 Calibrating maximum and minimum values of proportional outputs
1. Start up the radio remote control.
2. Press the TEACH pushbutton in the receiving unit and do not release it until the SETUP
LED illuminates.
3. Set the desired values as follows:
- To set the maximum value, move the joystick to the maximum range of the semi-axis
to be calibrated. Maintain the position and use the TEACH selector on the transmitting
unit to set the desired value.
- To set the minimum value, move the joystick slightly out of the rest position of the
semi-axis to be calibrated. Maintain the position and use the TEACH selector on the
transmitting unit to set the desired value.
- After calibrating one joystick, press the STOP pushbutton to save calibrations.
Calibrations are saved in the data memory on the DTK connector.
4. To set other values, unlock the STOP pushbutton, press the START pushbutton and
repeat actions described in the previous point.
5. To leave the procedure, press the TEACH pushbutton on the receiving unit and do not
release it until the SETUP LED switches o.
If the proportional outputs are activated by actuators that are not joysticks (i.e.
potentiometer, switch), calibrate maximum and minimum values according to the
above mentioned procedure.
If a speed selector is present on the transmitting unit, minimum and maximum
values have to be calibrated for each of the selector positions.
If inputs are used in the receiving unit to select dierent speeds, calibration must
be performed for any possible conguration of the inputs.
AUTEC - Dynamic Series
Values of proportional outputs 7
LIARXE00-00
