7 Malfunction signalled by the receiving unit
Use the light signals on the receiving unit to identify the radio remote control malfunction.
If the problem persists after the suggested solution has been carried out, contact the support
service of the machine manufacturer.
Signals Possible reason Solutions
The POWER LED is o󰓐.
The receiving unit is
switched o󰘯.
Disconnect the power supply and restore
it after 5 minutes to make sure that a
restorable thermal fuse integrated in the
receiving unit has not been activated.
Correctly plug in the connecting plug
and power on the receiving unit.
The POWER LED is on. No radio link.
Bring the transmitting unit close to the
receiving unit.
The ALARM LED blinks
once.
Error on the STOP
outputs.
Make sure that fuse F1 is intact.
Correctly plug in the connecting plug.
Make sure that the STOP outputs are
wired correctly.
The ALARM LED blinks
twice.
Error on the SAFETY
outputs.
Make sure that fuse F1 is intact.
Correctly plug in the connecting plug.
Make sure that the SAFETY outputs are
wired correctly.
The ALARM LED blinks
three times.
Error on the outputs
corresponding to direction
commands.
Contact the support service of the
machine manufacturer.
Make sure that the outputs of direction
commands are wired correctly.
The ALARM LED is on.
Con󰘰guration erroron the
SO1 and SO2 outputs.
Make sure that the DIP switches are set
as on the technical data sheet.
If this signal persists, contact the support
service of the machine manufacturer.
10
LIARXE00-00
Malfunction signalled by the receiving unit
AUTEC - Dynamic Series
