AUTEC Dynamic ARX User Manual

The SETUP LED... Meaning
... blinks quickly three times
The receiving unit is saving data set with the REMOTE
SETUP procedure (see chapter 6).
... blinks four times
Inversion of movement direction of the joystick's axis is
being performed within the REMOTE SETUP procedure
(see paragraph 6.3).
... blinks fast
Within the REMOTE SETUP procedure:
- two or more analogue commands are being activated
simultaneously or
- factory settings are being restored (see paragraph 6.4)
... is on
Calibration of maximum and minimum values of
proportional outputs is being performed within the
REMOTE SETUP procedure (see paragraph 6.1).
6 Values of proportional outputs
Proportional outputs in the ARX receiving unit are factory set: values are given in the technical
data sheet.
The REMOTE SETUP procedure is used to modify:
- maximum and minimum values of proportional outputs (see paragraph 6.1)
- rest position values related to the proportional outputs (o󰘯set) (see paragraph 6.2)
- movement direction of the joystick's axis (see paragraph 6.3)
The REMOTE SETUP procedure can only be performed by skilled and
properly trained personnel.
During the REMOTE SETUP procedure, pay particular attention to the machine
behaviour, as it moves as a response to acting on the actuators.
6
LIARXE00-00
Values of proportional outputs
AUTEC - Dynamic Series
