7.2 Light signals on the LK NEO 6 DF Transmitting Unit (Model LKN Type
DA1DM)
Display icons
A Red LED
B Green LED
D Battery
E Radio link
The following icons are always available on the display of LK NEO 6 DF Transmitting Units:
- red LED [A] and green LED [B] providing information about the Radio Remote Control,
- battery [D] providing indication of the battery power level,
- radio link [E] providing indication of radio link strength.
The meaning of other icons shown on the display is explained in the "Data
Feedback" function part (see paragraph 8.16). The meaning of such icons is
decided and established by the Manufacturer depending on the Machine's functions
for which he wants to receive information.
7.2.1 Red LED [A] and green LED [B]
The meaning of red LED [A] and green LED [B] signals is described in the following tables;
possible actions to carry out are given in chapter 11.
The meaning of the red and green LED signals cannot be modi󰘰ed.
Signal Meaning
The green LED [B] is o󰓐. The Transmitting Unit is o󰘯.
The green LED [B] is lit with a
steady light.
The Transmitting and Receiving Unit do not communicate.
AUTEC - AIR SERIES
Light signals 21
LIULK6N03_eng-00
