8.17 BACK-UP UNIT
If the Transmitting Unit cannot be used, it can be replaced with a Transmitting Unit called
"BACK-UP UNIT"; you need to ask for it from Autec.
It is identical to the Unit that can no longer be used; the only dierence is the presence of
the plate “BACK-UP UNIT” on the battery housing.
Set DIP switch 2 in the "BACK-UP UNIT" as shown in the Technical Data Sheet.
If no "Key ID 0-1" or "ID internal tx memory" is present in the Transmitting
Unit that can no longer be used, perform the PAIR procedure to pair the
“BACK-UP UNIT” with a Receiving Unit (the Technical Data Sheet shows
which PAIR procedure to use).
If a "Key ID 0-1" or an "ID internal tx memory" is present in the Transmitting
Unit that can no longer be used, move it to the "BACK-UP UNIT" and perform
the address saving procedure described below.
As required by standard IEC 60204-32, each Radio Remote Control is uniquely
identied through a serial number. Therefore, upon replacement of the Unit,
the serial number of the Transmitting Unit to be replaced must be marked
on the "BACK-UP UNIT", so that all Units belonging to the Radio Remote
Control will show the same serial number.
Autec cannot be held responsible if the serial number of the Transmitting
Unit to be replaced has not been marked on the "BACK-UP UNIT".
AUTEC - AIR SERIES
General operating instructions 35
LIULK6N03_eng-00
