Autel MaxiDASMaxiCheck DS808 - Other Accessories

5
Dimensions (W x H x D)
237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm
(1.4”)
Net Weight
788 g (2.42 lb.)
Supported Automotive
Protocols
ISO9141-2, ISO14230-2,ISO15765, K/L-Line,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, ISO11898(Highspeed, Middlespeed,
Lowspeed and Singlewire CAN,fault-tolerant
CAN), SAE J2610,GM UART,UART Echo Byte
Protocol, Honda Diag-H Protocol, TP2.0, TP1.6
Other Accessories
Main Cable
The Main Cable connects the Display Tablet to the vehicle’s data link
connector (DLC).
Other Accessories
Mini USB Cable
Connects the Display Tablet to the PC or USB external
power adapter.
USB External Power Adapter
Together with the mini USB cable, connects the
Display Tablet to the external DC power port for power
supply.
Figure 2-4 Main Calbe
