Autel MaxiScan MS309 - Viewing Freeze Frame Data

4.3 Viewing Freeze Frame Data
1) To view freeze fram, use SCROLL button to select View
Freeze Frame from Diagnostic Menu and press ENTER/EXIT
button.
............Diagnostic Menu..........
3/6
1) Read Codes
2) Erase Codes
►3) View Freeze Frame
4) I/M Readiness
z If more than one module is detected, you will be prompted
to select a module before test.
…………….Control Module…………….
1/3
► Engine
Module $A4
Exit
z Use SCROLL button to select a module and press
ENTER/EXIT button.
2) Wait a few seconds while the code reader validates the PID MAP.
……………View Freeze Frame……...
Reading PID.01
- Please Wait -
3) If the retrieved information covers more than one screen, use
SCROLL button, as necessary, until all data have been shown up.
18
