Autel MaxiTPMS TS401 - Tool Specifications and Dimensions; Included Accessories with the Tool

5
4) N BUTTON – Cancels a selection (or action) from a menu
or return to previous menu.
5) DOWN SCROLL BUTTON – Moves down through
menu and submenu items in menu mode. When more than one
set of data are retrieved, use this button to move down to next
screens for additional data.
6) HELP BUTTON – Provides help information.
7) POWER BUTTON – Turns on/off the tool.
8) Y BUTTON – Confirms a selection (or action) from a
menu or return to previous menu.
9) TEST BUTTON – Commences a TPMS test.
10) USB PORT – Connects the TPMS tool to computer with the
USB cable supplied to update the device or for charging.
11) POWER PORT – Connects the TPMS tool to the mains with
the charger supplied for battery charging.
3.2 Specifications
1) Display: Backlit 128*64 pixel display with contrast adjustment
2) Power: 3.7V Li-polymer battery
3) Operating Temperature: 0 to 50°C (32 to 122 °F)
4) Storage Temperature: -20 to 70°C (-4 to 158 °F)
5) Dimensions:
6) Length Width Height
195.5 mm (7.7") 104 mm (4.09") 37.5 mm (1.48")
7) Weight: 0.37 kg (0.82 lb.)
3.3 Accessories Included
1) User’s Manual -- Instructions on tool operations.
