previous screens, if recorded data content covers more than one
screen.
6. DOWN SCROLL BUTTON – moves down through menu and
submenu items in menu mode. When more than one set of data are
retrieved, use this button to move down to next screens for additional
data. It is also used to view next trouble code when viewing DTCs.
7. HELP BUTTON – provides help information.
8. POWER BUTTON – long press the button to turn on/off the tool; or,
short press the button to return to Home screen.
9. RIGHT SCROLL BUTTON – when scrolling through a screen of
data or text, moves to next character and view additional information on
next screens, if recorded data content covers more than one screen.
10. TEST BUTTON – commences a TPMS Test or confirms selections
on screen.
11. Y BUTTON – confirms a selection (or action) from a menu.
12. USB PORT – connects the TPMS tool to PC for software update, or
battery charging.
NOTE
Figures and illustrations, product’s characteristics and functions, and
included accessories in this User Manual are provided for reference only and
may differ from actual product. Product design and specifications may be
changed without notice.
Specifications
Table 3-1 Specifications
