7
Accessories Included
User Manual – instructions on tool operations
USB Cable Adapter – allows easy online update, and power charging
via PC connection or connect the device and power source with the
Adapter
Carry Case – a case to store the tool when not in use
Magnet – used to trigger magnetically activated sensors (early model
TPMS sensors)
CD – includes user’s manual and PC Suite
Icons
1. – indicates battery charging.
2. – indicates there is data stored in the tool.
3. – indicates battery volume.
4. – indicates USB communication with the computer is established.
5. – indicates magnet is required to activate TPMS sensor.
6. – indicates deflation is required to activate TPMS sensor.
7. – indicates wheels will be checked one by one.
8. – indicates the TPMS tool is sending signals to the tire sensor for
activation and test in activation screen or indicates the sensor
information is read by activation.
Keyboard
No solvents such as alcohol are allowed to clean the keypad or display. Use
a mild nonabrasive detergent and a soft cotton cloth. Do not soak the keypad
as the keypad is not waterproof.
Battery Charging
The TPMS tool has a 3.7 V built-in lithium-ion polymer rechargeable battery.
How to charge battery:
To charge battery by USB cable via PC connection
1. Locate the USB port of the device.
2. Connect the device and the computer with the USB cable.
To charge battery by USB cable adapter
