2
Place the snorkel (E) on the gasket (F) inserting
the snorkel mouths in the gaskets openings.
3
Lower the glass window by about 20 cm and place gasket (F) with snorkel (E) on it, placing the glass in the
gasket’s groove.
4 Lift the glass window until the gasket (F) is flush with the window’s original gasket.
