Autoclima U-GO User Manual

ENGLISH
34/78
6.6 - MODE OF OPERATION (COOLING OR HEATING)
“U-GO” can operate in two modes: COOLING or HEATING.
Based the chosen operating mode, the tubing must be connected accordingly.
WARNING: it is necessary that all air intake and air output openings of “U-GO” are maintained free of debris or
obstructions; place “U-GO” where there is enough space around, and not, for example, next to curtains; do not
place clothes, rags or any other object which may obstruct the airflow.
COOLING MODE: connect the two flexible tubing (B) between “U-GO” (openings 3 and 4) and the snorkel (E)
by means of the entrance nozzles (C) located at the tips of the tubing. Cool air will exit from outlet air nozzles
1 and 2.
If you wish to ventilate air remotely, connect the other (1 or 2) supplied flexible tubing (B), securing them to the
outlet air nozzles (1 and 2).
