1
INSTRUCTION MANUAL
LIFT ONDA
DEVICE
ONDA OB Series
ONDA OW Series
ONDA OS Series
MODELS
ORIGINAL INSTRUCTIONS
00
REVISION
2020
YEAR

Table of Contents

Questions and Answers

  • J
    John BlakeAug 2, 2025
    Why does my AUTOLIFT ONDA OB platform not move?
    • G
      Gina ShepherdAug 2, 2025
      The platform might not be moving due to several reasons: * The main power switch may be OFF. In this case, position the main power switch to ON. * The hydraulic power pack fuse could be open; try resetting it. * The main fuse or the electronic control unit fuse may be blown, requiring replacement. * A faulty pendant switch, intermittent power on the solenoid line, defective lowering valve solenoid, broken lowering valve, or a broken electronic control unit could also be the cause, each requiring replacement. * For SKY and BBW models, blocked platform hinges could be the issue; lubricate them with oil and grease. * Finally, restore continuous power to the solenoid line if there is intermittent power.
  • S
    Susan SullivanAug 7, 2025
    What to do if my AUTOLIFT ONDA OB platform does not descend?
    • C
      Christopher MoralesAug 7, 2025
      If the platform isn't descending, check these potential causes: * The pendant switch might be disconnected or faulty; connect or replace it. * There might be intermittent power on the solenoid line; restore continuous power. * A defective lowering valve solenoid or broken lowering valve could be the issue; replace them. * The flow control valve may be occluded; clean off any dirt. * Lastly, a broken electronic control unit may be the cause; replace it.
  • J
    jennifer39Aug 11, 2025
    Why won't my AUTOLIFT ONDA OB platform rise?
    • T
      timothy05Aug 11, 2025
      If the platform is not rising, consider the following possibilities: * The lowering valve emergency screw might not be tight; tighten it. * The lowering valve, power pack starting relay, or hydraulic power pack could be defective; replace them as needed. * A faulty pendant switch or broken electronic control unit may also be responsible; replace them. * Ensure the battery has sufficient charge and clean any dirty earth connections. * Restore continuous power to the solenoid line if there is intermittent power.
  • J
    Jeffrey FergusonAug 15, 2025
    What should I do if my AUTOLIFT ONDA OB platform does not stop at the loading surface when rising?
    • T
      Tonya PerezAug 15, 2025
      If the platform doesn't stop at the loading surface when rising, check these items: * The micro M1 may not be connected correctly; ensure it is properly connected. * There may be intermittent power on the micro M1 line; restore continuous power. * The micro M1 cam might not be adjusted correctly; adjust it accordingly. * The micro M1 may be broken; replace it if necessary.
  • D
    dukesharonAug 19, 2025
    How to fix misaligned movement of AUTOLIFT ONDA OB platform?
    • C
      cyoungAug 20, 2025
      If the platform movement is not aligned, it could be due to: * A cylinder valve being occluded; clean off any dirt. * A damaged cylinder gasket; replace the gasket. * A damaged hydraulic cylinder; replace the cylinder.
  • J
    Jeremy SuttonAug 23, 2025
    What to do if my AUTOLIFT ONDA OB Lifting Systems platform does not close?
    • K
      Karen MartinAug 23, 2025
      If the platform is not closing, check these possible causes: * The lowering valve emergency screw might not be tight. * The pressure switch might not be adjusted correctly; adjust it. * The lowering valve, power pack starting relay, or hydraulic power pack could be broken; replace them as necessary. * A faulty pendant switch or broken electronic control unit may also be the cause; replace them.
  • R
    Rebecca MayoAug 28, 2025
    What should I do if my AUTOLIFT Lifting Systems platform does not stop at the loading surface when opening (item 9 in list of components)?
    • K
      Kristen RoseAug 28, 2025
      If the platform is not stopping at the loading surface when opening, check if: * Micro M1 is not connected correctly; correctly connect the control wire. * There is intermittent power on the micro M1 line; restore continuous power to the micro M1 line. * The micro M1 cam is not adjusted correctly; correctly adjust the micro M1 cam. * Micro M1 is broken; replace the micro M1.

Summary

General Warnings

Manufacturer and Marking Information

Details about the lift manufacturer and product identification plate compliance.

Operator Identification and Responsibilities

Defines operator roles and their essential physical, mental, and emotional requirements.

Safety Rules and Manual Usage

Key safety rules for operation and guidelines on using the instruction manual.

General Description

Components Identification

Identifies and labels the main parts of the lift device using numbered references.

Dimensions and Technical Data

Presents detailed dimensions and technical specifications for various lift models.

Field of Use

Intended and Improper Use

Specifies the lift's intended applications and lists forbidden or improper actions.

Safety Devices

Overview of Safety Features

Lists and describes integrated safety devices designed to protect users and the lift.

Warning Signs

Understanding Warning Markings

Explains the meaning of various pictograms and safety labels found on the lift.

Installation

Receipt and Inspection Procedure

Steps for checking the lift upon delivery to ensure completeness and integrity.

Storing and Non-Use Guidelines

Instructions for storing the lift when not in use to prevent damage.

Transport and Packaging Information

Details on how the lift is packaged and transported, including dimensions.

Handling and Packaging Removal

Guidelines for safely handling the lift and removing its packaging.

Vehicle Installation Process

Step-by-step guide for installing the lift onto a vehicle.

Electrical Installation Guide

Instructions for connecting the lift's power supply and wiring system.

Use

Normal Operation

Step-by-step guide on how to operate the lift under normal conditions using the remote control.

Emergency Operation

Procedures for operating the lift manually in the event of an electrical power failure.

Cleaning

Cleaning Instructions

Guidelines for cleaning the lift using appropriate methods and non-aggressive detergents.

Adjustements

Setting Floor Level Stop

Explains how to adjust the microswitch cams to change the lift's floor level stopping position.

Maintenance

Periodic Inspection

Outlines the requirements, scope, and schedule for periodic technical inspections of the lift.

Control Frequency

Provides a table detailing the recommended frequency for various operational checks and controls.

Demolition and Disposal

Disposal Procedures

Guidelines for safely decommissioning and disposing of the lift according to legal requirements.

Troubleshooting

Failure Modes and Solutions

A table listing common operating failures, their causes, and recommended solutions.

Wiring Diagram

Standard Wiring Diagram

Illustrates the standard electrical connections and layout of the lift system.

Hydraulic Diagram

Hydraulic System Diagram

Shows the schematic representation of the lift's hydraulic system components and flow.

Spare Parts

Obtaining Spare Parts

Information on contacting the spare parts department and the process for requesting components.

AUTOLIFT ONDA OB Series Specifications

General IconGeneral
Load Capacity300 kg
Voltage220V
Power SupplyElectric
Control SystemPush-button control
Safety FeaturesEmergency stop button
