12 © 1999 Directed Electronics, Inc. Vista, CA
1. Using your wire strippers and razor knife, strip approximately
1
/2-inch of insulation off the wire to be con-
nected to, without cutting the wire.
2. Twist the security module’s wire around the bare section of the vehicle’s wire.
3. Solder the bare connection thoroughly using rosin core solder.
4. Completely insulate the connection with electrical tape.
