Automated Logic R683 User Manual

14
Rev. (30-JAN-98) • RLM v4.7 © 1995-98 Automated Logic Corporation
Parameter Page
Function Block Type: RLM (R-Line Module R683)
Name CM 09 User Defined Line 1 GCM 1 CM 9 FB 15 Flags —
ID ID21 Tele NB All Options Y Type 11 Ver 1
Alarms Enabled ———— Text 1 0 0 0 0 0 0 242
Messages Enabled ———— Text 0 0 0 0 0 4 0 0
This is the translation table for the custom gain of 15.00.
Is input specified in voltage? NO .
0 x10 Ohms = 296.0
143 x10 Ohms = 168.8
334 x10 Ohms = 125.6
599 x10 Ohms = 98.69
779 x10 Ohms = 87.44
1000 x10 Ohms = 77.00
1285 x10 Ohms = 66.88
1666 x10 Ohms = 56.75
3007 x10 Ohms = 34.94
6995 x10 Ohms = 6.38
32767x10 Ohms = -60.2
This is the translation table for the custom gain of 15.06.
Is input specified in voltage? YES.
0 Millivolts = 0.00
500 Millivolts = 50.00
1000 Millivolts = 100.0
1500 Millivolts = 150.0
2000 Millivolts = 200.0
2500 Millivolts = 250.0
3000 Millivolts = 300.0
3500 Millivolts = 350.0
4000 Millivolts = 400.0
4500 Millivolts = 450.0
5000 Millivolts = 500.0
Mask Outside Air Invalid condition? NO
HOA switch alarm delay 10:00 mm:ss
This module should display old-style FB trends NO
Enable debug screen NO (for Tech Support use)
Status Page
Function Block Type: RLM (R-Line Module R683)
Name CM 09 User Defined Line 1 GCM 1 CM 9 FB 15 Flags —
ID ID21 Tele NB All Options Y Type 0 Ver 0
Active Alarms ———— Active Messages ———— Status-Code 0
Real Module Address 0
This module contains the following function blocks:
HOA switches not in automatic position NO , alarm delay 0:00 mm:ss
Trending Information:
FB Exp Chan Trending Interval Samples
Module Drivers
