Channel Numbers
§ For ALC 0-20 mA sensors, use the offset & gain printed on the sensor. Otherwise, use the Point Help feature of SVW
2.0 or later.
† Degrees Celsius can only be displayed in SVW 1.1 or later when the GFB is made in Eikon 2.0 or later with the
"METRIC=TRUE" command set in the alc.ini file.
I/O Type Signal Type
Channel
Number
† Range Offset Gain
UI 1 Thermistor 31
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 2 Thermistor 32
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 3 Thermistor 33
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 4 Thermistor 34
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 5 Thermistor 35
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 6 Thermistor 36
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 7 Thermistor 37
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
UI 8 Thermistor 38
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
Zone
Sensor
Inp ut
(RS Z+)
Zone
Sensor
Inp ut
(RS Z+)
Thermistor
Thermistor
39
39
-17 to 213 °F 0.00 15.88
-27 to 100.6
°C
0.00 15.69
Setpoint
Adjust
Inp ut
(RS Z+)
Thermistor 3A -1, 0, 1 0.00 15.94
UI 1 mA or Volts 31
0-20 mA
0-5 V
§§
UI 2 mA or Volts 32
0-20 mA
0-5 V
§§
UI 3 mA or Volts 33
0-20 mA
0-5 V
§§
UI 4 mA or Volts 34
0-20 mA
0-5 V
§§
UI 5 mA or Volts 35
0-20 mA
0-5 V
§§
UI 6 mA or Volts 36
0-20 mA
0-5 V
§§
UI 7 mA or Volts 37
0-20 mA
0-5 V
§§
UI 8 mA or Volts 38
0-20 mA
0-5 V
§§
I/O Type
Signal
Type
Channel
Number
Range Offset Gain
UI 1 Digital 21
---
UI 2 Digital 22
---
UI 3 Digital 23
---
UI 4 Digital 24
---
UI 5 Digital 25
---
UI 6 Digital 26
---
UI 7 Digital 27
---
UI 8 Digital 28
---
Override
Switch
(RSZ+)
Digital 2A
---
DO 1 Digital 11
---
DO 2 Digital 12
---
DO 3 Digital 13
---
DO 4 Digital 14
---
DO 5 Digital 15
---
DO 6 Digital 16
---
Occupied
LED (RSZ+)
Digital 17
---
AO 1 Analog 41
0-10
VDC
0.0 0.0625
AO 2 Analog 42
0-10
VDC
0.0 0.0625
AO 3 Analog 43
0-10
VDC
0.0 0.0625
HOA Status
DO 1
Digital 81
---
HOA Status
DO 2
Digital 82
---
HOA Status
DO 3
Digital 83
---
HOA Status
DO 4
Digital 84
---
HOA Status
DO 5
Digital 85
---
HOA Status
DO 6
Digital 86
---
