TECHNICAL SPECIFICATIONS
Power supply:
Single phase 120 VAC (5A) to 240 VAC (3A) -
(+/-10%) -
50/60 Hz + Ground
The power supply must be protected by a 16 A circuit
breaker + 30 mA differential circuit breaker.
AISI 304L brushed stainless steel housing, 1.5 mm thick.
Steel frame with RoHS zinc-plated corrosion resistance.
Tempered safety glass obstacles (fixed and mobile), 10 mm thick.
Passage width (L): 600 mm 900 mm
Weight:
right unit:
104 kg 106 kg
left unit: 103 kg 105 kg
intermediate unit: 122 kg 127 kg
Power consumption (per lane): At rest: 20 W
During operation: 35 W
Maximum: 80 W
Motor (2 motors per lane): 24 VDC –Nominal output power: 86 W
Operating time: Opening: 0.7 sec 1 sec
Closing: 0.7 sec 1 sec
(depending on the access control system reactivity and the user speed)
Ambient temperature during use: +0 to +50 °C
Ambient relative humidity during use, non-condensing: < 95%
Protection rating (IP) 40
Sound level (at 1 m distance): 55 dB
MCBF (mean cycles between failures), with recommended maintenance: 2,000,000
Conforms to standards
