Intermediate unit
Ref.: Designation:
1 Extension cover
2 Top cover
3 Fixed glass
4 Reader cover
5 Orientation and function pictogram
6 Moving obstacle
7 Panel for access to the mechanism(s)
8 DIRAS cells behind tinted Plexiglass
1
4
5
7
2 3
7 8 6
6
4
5
8
