Automatic Systems TriLane TL Series - General Description

p. 12/46
TLxx-MT-EN-04
5. GENERAL DESCRIPTION
5.1. EXTERNAL DIMENSIONS
1300
=
880
=
210210
5 0920
510
750
235
Fig. 2 External dimensions, 2-leg TL2 version
400
100
750
977
338.5 510
Fig. 3 External dimensions, 1-leg TL1 version
