p. 41/46
TLxx-MT-EN-04
10. TECHNICAL DATA
Type Characteristics Value
Weight Weight without options and without
packaging (TL2)
60 kg
Weight Weight without options and without
packaging (TL1)
46 kg
Electrical Electrical power supply 100 - 230 V single-phase 50/60
Hz
Control circuit 24 VDC
Electro-magnets 30% duty cycle in order to reduce
heating
Consumption Standby mode < 20 W
Duty cycle < 55W
Max < 85W
Ambient Operating temperature: -10 °C to + 50 °C
IP rating IP44
Noise level 60 dB at 1 metre
MCBF Average number of cycles between
breakdowns
5,000,000 cycles
MTTR Mean time to repair 30 minutes
Flow (beyond reader response time) Up to 20 passages/minute,
depending on the reader type and
authorization speed
Complies with EC standards.
