p. 8/46
TLxx-MT-EN-04
3. GENERAL SYMBOLS
The following symbols are used in this manual or as labels on the equipment:
This symbol is used to highlight a tip that may help you to better understand the product.
This symbol is used to highlight an important instruction for the correct use and/or maintenance of
the product.
This symbol is used to highlight a risk of electric shock or electrocution.
This symbol is used to highlight a risk of cutting yourself.
This symbol is used to identify the ground connection point.
(Either in the form of an affixed label or directly engraved on a mechanical part)
13
This symbol is used to indicate the tool to be used for the relevant operation.
This symbol indicates that the equipment conforms to European standards and directives.
This symbol indicates that the equipment must be disposed of in accordance with the applicable
European Directives (DEEE 2012/19/EU).
