13
7.1.2. Gauge Electrical Data
Electrical Data
Protection rating III
Device power supply 2 x Batterys 1,5 V (type AA)
Battery life without operation at min. 50 %
battery capacity
> 1 year
Battery life at one measurement per second approx. 60 000 measurements
7.2. Probe Technical Data
7.2.1. Probe Mechanical Data
Mechanical data
Upper housing material Stainless steel (1.4305)
Bottom housing material Trogamid® (CX7323)
Test prod material polished ruby (Al203)
Dimensions (length / diameter) 35,5 mm / 14,5 mm
Weight 11,9 g
Robustness / ambient conditions
IP-rating IP65 (closed)
Operating temperature -20 °C to +70 °C
Storage temperature -20 °C to +70 °C
Max. surface temperature in continuous
measurement mode
80 °C
Max. surface temperature at 1s test time every 20s 100° C
