GS1 Series AC Drive User Manual
4–27
Chapter 4: AC Drive Parameters
Multi-function Output Terminal Mem Addr 030BH(40780)
Default Setting: 0
Settings: 0 AC Drive Running
1 AC Drive Fault
2 At Speed
3 Zero Speed
4 Above Desired Frequency (3-16)
5 Below Desired Frequency (3-16)
6 At Maximum Speed (0-02)
7 Over Torque Detected
8 Above Desired Current (3-17)
9 Below Desired Current (3-17)
Function Explanations:
Setting 0: AC Drive Running—The terminal will be activated when there is an
output from the drive.
Setting 1: AC Drive Fault—The terminal will be activated when a fault occurs.
Setting 2: At Speed—The terminal will be activated when the AC drive attains the
Command Frequency (4-00).
Setting 3: Zero Speed—The output will be activated when Command Frequency
(4-00) is lower than the Minimum Output Frequency (2-06).
Setting 4: Above Desired Frequency—The output will be activated when the AC drive
is above the Desired Frequency (3-16).
Setting 5: Below Desired Frequency—The output will be activated when the AC drive
is below the Desired Frequency (3-16).
Setting 6: At Maximum Speed—The output will be activated when the AC drive
reaches Motor Maximum RPM (0-04).
Setting 7: Over Torque Detected—The output will be activated when the AC drive
reaches the Over-torque Detection Level (6-08) and exceeds this level for
a time greater than the Over-torque Detection Time (6-09).
Setting 8: Above Desired Current—The output will be activated when the AC drive is
above the Desired Current (3-17).
Setting 9: Below Desired Current—The output will be activated when the AC drive is
below the Desired Current (3-17).
3-11
