Typical Connections to the GS1 Series AC Drive
The following drawings show some typical connections between the GS1 Series
AC Drive and DirectLOGIC PLCs and modules.
DC Output Modules
Appendix B: Using GS1 AC Drives with DirectLOGIC PLCs
GS1 Series AC Drive User Manual
B–6

햲
햳
햴
C
+V
+24 VDC
DC Output Module
Control circuit terminal Shielded leadsMain circuit (power) terminals
GS1-xxxx
T3
T1
T2
+10V 10mA
(max)
AI
CM
L1
L3
L2
R1O
R1
16
DI1
DI2
DI3
DI4
CM
• D0-05DD
• D0-05DD-D
• D0-06DD1
• D0-06DD1-D
• D0-10TD1
• D0-16TD1
• D2-16TD1-2
• D2-32TD1
• D4-08TD1
• D4-16TD1
• D4-32TD1
• T1K-08TD1
• T1K-16TD1
