GS1 AC Drive Dimensions
Chapter 2: Installation and Wiring
GS1 Series AC Drive User Manual
2–4
I
DI4AIR1OR1 + 10V DI2DI1 DI3 CM
1000
V
STOP
RUN
ENTER
PROG
DISPL
RESET
FWD
RUN
REV
STOP
68.0 (2.68)
56.0 (2.20)
d
ia
. 5.0 (0.20)
120.0 (4.72)
132.0
(
5.20)
123.4
(
4.8
6
)
128.1 (5.04)
Unit: mm (in)
