GS Series Number Mem Addr: 0929H(42346)
Default Setting: ##
Settings: 1 GS1
2GS2
3GS3
4GS4
Manufacturer Model Information Mem Addr 092AH(42347)
Default Setting: ##
Settings: 0 GS1-10P2 (120V, 1ph, 0.25HP)
1 GS1-10P5 (120V, 1ph, 0.5HP)
2 GS1-20P2 (230V, 1ph/3ph, 0.25HP)
3 GS1-20P5 (230V, 1ph/3ph, 0.5HP
4 GS1-21P0 (230V, 1ph/3ph, 1HP)
5 GS1-22P0 (230V, 3ph, 2HP)
9-42
9-41
Chapter 4: AC Drive Parameters
GS1 Series AC Drive User Manual
4–50
