Page 2–6 SureServo2 User Manual – 1st Edition – 05/20/2021
Chapter 2: Installation
Monitoring DI/DO Codes ParametersAlarms Wiring
Caution: The builT-in brake is noT a device for safely sTopping The machine. please insTall
anoTher safeTy sTopping device for The machine. when The builT-in brake is clamping The
moTor, roTaTion backlash can sTill occur and The maximum roTaTion is 1° – 2°. when a
moTor wiTh a brake is operaTing, The brake lining someTimes generaTes a noise (a swishing or
clicking sound). This is caused by The sTrucTure of brake module and is noT a malfuncTion.
iT will noT affecT The moTor’s funcTion.
•
If any odor, noise, smoke, vapor, or abnormal vibration occurs during motor operation, please
stop the motor and turn off the power immediately�
Others
•
SureServo2 servo motors have no user-replaceable parts�
•
Do not disassemble the motor or change its parts� Permanent damage or malfunction of the
motor may occur� This will void the warranty�
•
Do not splash water or oil on the product�
SV2A-2040
100–120 VAC 1-phase
200–230 VAC 1-phase
3�98 A
4�69 A
10A 15A
Class CC
200–230 VAC 3-phase 2�76 A 10A 10A
SV2A-2075
100–120 VAC 1-phase
200–230 VAC 1-phase
7�73 A
8�71 A
20A 20A
200–230 VAC 3-phase 5�09 A 13A 15A
SV2A-2150
100–120 VAC 1-phase
200–230 VAC 1-phase
12�56 A
14�82 A
30A 30A
200–230 VAC 3-phase 8�09 A 20A 25A
SV2A-2200
100–120 VAC 1-phase
200–230 VAC 3-phase
18�03 A
20�83 A
40A 40A
Class J
or
High Speed J*
200–230 VAC 3-phase 11�36 A 30A 35A
SV2A-2300 200–230 VAC 3-phase 14�52 A 35A 50A
SV2A-2550
200–230 VAC 3-phase 27�06 A 60A 70A
SV2A-2750 200–230 VAC 3-phase 37�33 A 70A 80A
SV2A-2F00 200–230 VAC 3-phase 69�96 A 120A 125A
The values in the table above are maximum allowable values to be used with the listed drives.
The maximum values are well above the drive rated input current. Most applications can
use much lower fuse/breaker values. A smaller value of 125% - 175% of rated input current
is recommended. This allows for temporary motor overloads without tripping the circuit
protection.
The SureServo2 drives have an SCCR rating of 5kA. For short circuit protection, choose a
current-limiting fuse that limits the let-through current (at your installation's available fault
current level) to less than 5,000 Amps. For SureServo2, ADC recommends Class CC or JHL High
Speed Class J current-limiting fuses.
Example:
The time-current chart for JHL drive-rated fuses shows that a 30A JHL fuse will allow 50A for
an extended period of time before blowing.
A smaller fuse/breaker rating also helps with SCCR. The 30A JHL fuse above has a peak
let-through of less than 2,500A when connected to 100,000A RMS available fault current. A
60A JHL would allow a 5,000A peak with the same available RMS fault current. Using a smaller
fuse is better for device protection and SCCR ratings.
