2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 19
2 Modbus Mapping Table
2.1 Reset/Output
No (Address) Func Explanation Setting range Notice
000001 (0000) 01/05
Reset
1
0: OFF 1: ON -
000002 (0001) 01 OUT2 output 0: OFF 1: ON -
000003 (0002) 01 OUT1 output 0: OFF 1: ON -
000004 (0003) 01 BATCH output 0: OFF 1: ON For BATCH output model
000005 (0004) 01/05
BATCH resets
1
0: OFF 1: ON For BATCH output model
1: For Reset/BATCH resets ON using Func.05, input FF00 H to DATA.
For more information, refer to '1.5 Force Single Coil (Func 05-05 H).
2.2 Terminal input status
No (Address) Func Explanation Setting range Notice
100001 (0000) 02 INA input status 0: OFF 1: ON Terminal input status
100002 (0001) 02 INB input status 0: OFF 1: ON Terminal input status
100003 (0002) 02 INHIBIT input status 0: OFF 1: ON Terminal input status
100004 (0003) 02 RESET input status 0: OFF 1: ON Terminal input status
100005 (0004) 02 BATCH RESET input status 0: OFF 1: ON Terminal input status
