Autonics CT Series User Manual

2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 23
2.6 Function setting mode
2.6.1 Counter group
No (Address) Func Explanation Setting range Notice
400051 (0032) 03/06/16
Counter/Timer
[C-T]
0: COUN 1: TIME
Use counter and
timer in common
400052 (0033) 03/06/16 Input mode [IN]
0: UP
1: UP-1
2: UP-2
3: DN
4: DN-1
5: DN-2
6: UD-A
7: UD-B
8: UD-C
-
400053 (0034) 03/06/16
Indication mode
[DIsM]
0: TOTAL 1: HOLD For the indicator
400054 (0035) 03/06/16
Output mode
[OUtM]
0: F
1: N
2: C
3: R
4: K
5: P
6: Q
7: A
8: S
9: T
10: D
-
400055 (0036) 03/06/16
Max. counting
speed [CPS]
0: 1
1: 30
2: 1K
3: 5K
4:10K
-
400056 (0037) 03/06/16
OUT2(OUT)
output time
[OUT2(OUtT)]
)01 to 9(99
Unit: ×10ms
400057 (0038) 03/06/16
OUT1 output
time [OUT1]
)01 to 9(99
400058 (0039) 03/06/16
Decimal point
[DP]
0: ------
1: -----.-
2: ----.--
3: ---.---
4: --.----
5: -.-----
4-digit type
0: ---- 2: --.--
1:
---.-
3:
-.---
400059 (003A) 03/06/16
Min. reset time
[RST]
0: 1 1: 20 Unit: ms
400060 (003B) 03/06/16
Prescale
decimal point
position [ScDP]
1: -----.-
2: ----.--
3: ---.---
4: --.----
5: -.-----
4-digit type
1: ---.- 3: -.---
2: --.--—
400061 (003C)
03/06/16
Prescale value
[SCL]
6-digit type
: )00001 to 9999(9
4-digit type: )001 to 99(9
Connected with
prescale decimal
point position
400062 (003D)
400063 (003E)
03/06/16
Start value
[STRT]
6-digit type
: 000000 to 999999
4-digit type: 0000 to 9999
Connected with
decimal point
position of display
value
400064 (003F)
400065 (0040)
03/06/16
Memory
protection
[DATA]
0: CLR 1: REC
Use counter and
timer in common
400066 (0041) Lock key [LOCK]
0: lOFF
1: LOc1
2: LOc2
3: LOc3
