Autonics CT Series User Manual

2 Modbus Mapping Table
22 © Copyright Reserved Autonics Co., Ltd.
Data format of 310001(03E8) address bit.
Bit Explanation Data
Bit 0 - 0
Bit 1 - 0
Bit 2 - 0
Bit 3 - 0
Bit 4 - 0
Bit 5 BA.O 0 or 1
Bit 6 OUT2 0 or 1
Bit 7 OUT1 0 or 1
Bit 8 - 0
Bit 9 - 0
Bit 10 BA.S 0 or 1
Bit 11 Lock 0 or 1
Bit 12 PRESET2 0 or 1
Bit 13 PRESET1 0 or 1
Bit 14 TMR 0 or 1
Bit 15 CNT 0 or 1
※2 words data format: upper data has high number address.
E.g.) 310004: present value (low word), 310005: present value (high word)
2.5 Preset value setting group
No (Address) Func Explanation Setting range Notice
400001 (0000)
03/06/16
PRESET2 setting value
PRESET setting value
Counter
6-digit type: 0 to 999999
4-digit type: 0 to 9999
Timer: within time setting range
Use counter and
timer in common
400002 (0001)
400003 (0002)
03/06/16 PRESET1 setting value
400004 (0003)
400005 (0004)
03/06/16
BATCH counter setting
value
0 to 999999
400006 (0005)
