2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 21
2.4 Monitoring data
No (Address) Func Explanation Setting range Notice
310001 (03E8) 04
BA.O LED display status 0: OFF 1: ON Bit 5
OUT2 LED display status 0: OFF 1: ON Bit 6
OUT1 LED display status 0: OFF 1: ON Bit 7
BA.S LED display status 0: OFF 1: ON Bit 10
LOCK LED display
status
0: OFF 1: ON Bit 11
PRESET2 LED display
status
0: OFF 1: ON Bit 12
PRESET1 LED display
status
0: OFF 1: ON Bit 13
TMR LED display status 0: OFF 1: ON Bit 14
CNT LED display status 0: OFF 1: ON Bit 15
310002 (03E9)
04
Present value of BATCH
counter
0 to 999999
For BATCH output
model
310003 (03EA)
310004 (03EB)
04
Present value of
counter/timer
Counter
6-digit type: -99999 to 999999
4-digit type: -999 to 9999
Timer: within time setting range
Use counter and timer in
common
310005 (03EC)
310006 (03ED) 04 Display unit
Counter
: decimal point of display value
Timer: time range
Counter: 400058 data
Timer: 400102 data
310007 (03EE)
04
PRESET2 setting value
PRESET setting value
Counter
6-digit type: -99999 to 999999
4-digit type: -999 to 9999
Timer: within time setting range
Use counter and timer in
common
310008 (03EF)
310009 (03F0)
04 PRESET1 setting value
Counter
6-digit type: -99999 to 999999
4-digit type: -999 to 9999
Timer: within time setting range
310010 (03F1)
310011 (03F2)
04
Setting value of BATCH
counter
0 to 999999
310012 (03F3)
310013 (03F4) 04 Checking the input logic 0: NPN 1: PNP -
