Autonics CX Series Manual

J-20
CX Series
Output Operation Mode (Counter)
Retained output
One-shot output (0.01 to 99.99 sec)
Retained output
One-shot output
※
OUT1
is available to set as ‘0’ regardless of output mode. The output for '0' setting executes.
※
In case of
C
,
R
,
P
,
Q
output mode for
OUT2
, setting ‘0’ is not available.
Output
mode
Input mode
Operation
Up, Up-1, 2, 3 Down, Down-1, 2, 3 Up/Down A, B, C
F
[
F
]
RESET
999999
SET2
0
1
SET
OUT1
OUT2
(OUT)
※
After count-up, counting display
value increases or decreases until
reset signal is applied and retained
output is maintained.
N
[
N
]
RESET
999999
SET2
0
1
SET
OUT1
OUT2
(OUT)
※
After count- up, counting display
value and retained output are
maintained until reset signal is
applied.
C
[
C
]
RESET
999999
SET2
0
1
SET
OUT1
OUT2
(OUT)
※
When count-up, counting display
value will be reset and count
simultaneously.
※
OUT1 retained output will be off after
OUT2 one- shot time.
※
The one-shot output time of OUT1
one-shot output time is operated
regardless of OUT2 output.
R
[
R
]
RESET
999999
SET 2
0
1
SET
OUT1
OUT2
(OUT)
※
After count-up, counting value
display is reset after one-shot
output time of OUT2 and it counts
simultaneously.
※
OUT1 retained output will be off after
OUT2 one-shot time.
※
OUT1 one-shot output time is
operated regardless of OUT2 output.
K
[
K
]
RESET
999999
SET2
0
1
SET
OUT1
OUT2
(OUT)
※
After count-up, counting display
value increases or decreases until
RESET input is applied.
※
OUT1 retained output is off after
OUT2 one-shot time.
※
OUT1 one-shot output time is
operated regardless of OUT2 output.
P
[
P
]
RESET
999999
0
SET2
1
SET
OUT1
OUT2
(OUT)
※
After count-up, counting display
value is maintained while OUT2
output is on.
Counting value is internally reset and
counts simultaneously.
※
When OUT2 output is off, displays
counting value while OUT2 is ON,
and it increases or decreases.
※
OUT1 retained output is off after
OUT2 one-shot time.
※
OUT1 one-shot output time is
operated regardless of OUT2 output.
Q
[
Q
]
RESET
999999
SET2
0
1
SET
OUT1
OUT2
(OUT)
※
After count-up, counting display
value increases or decreases during
OUT2 one-shot time.
※
OUT1 retained output is off after
OUT2 one-shot time.
※
OUT1 one-shot output time is
operated regardless of OUT2 output.
A
[
A
]
RESET
999999
0
SET2
1
SET
OUT1
OUT2
(OUT)
※
After count-up, counting display
value and OUT1 retained output
are maintained until RESET input is
applied.
※
OUT1 one-shot output time is
operated regardless of OUT2 output.
