J-24
CX Series
Zero blanking display
PV is displayed with zero blanking for the highest unit.
E.g.) When time range is 99m59.99s and PV is 00m04.05s, zero blanking is applied to minute which is the highest unit.
At the below digits of decimal point, it is not applied.
It displays as “
0
:
04
.
05
”.
Display type of the setting value display component by output mode
- In case of 2-stage setting model (CX6 -2P ) and
OND
,
ONd1
,
ONd2
,
ONd3
,
INt2
output mode, there are SET1 and SET2 setting.
It displays the each SV and the SET1, SET2 indicator turns ON when displaying or setting the each SV.
-In case of 1-stage setting model (CX6 -1P ) , SET is available and there is one setting value.
-In case of 1-stage setting model (CX6 -1P ),
INt2
output mode is not available.
-
FLK
output mode has
tOFF
,
tON
setting values. In case of 2-stage setting model (CX6 -2P ) and 1-stage setting model
(CX6 -1P ), each SET2, SET display is available.
(
tOFF
,
tON
setting value is for OUT2 output. It displays SET2 or SET.)
- The other output modes display SET2 or SET and have one setting value.
(only for 1-stage setting model (CX6 -1P ))
Switching display of the setting value display component
Select the display value at the setting value display component.
Depends on output mode, there are manual display switching and auto display switching.
- Manual display switching
1) In case of 2-stage setting model (CX6 -2P ) and
OND
,
ONd1
,
ONd2
,
ONd3
output mode, it is available.
2) In run mode, whenever pressing the key, the setting value display component displays SET1, SET2 SV in turn.
In case of 1-stage setting model (CX6 -1P ), it is not available.
- Auto display switching
1) When output mode is
FLK
,
NFD
,
NFd1
for 1-stage or 2-stage setting model (CX6 -1/2P ) and
INt2
mode for 2-stage setting
model (CX6 -2P ), the setting value display component automatically displays the set times depends on the operation status.
RESET
-In RUN mode, function setting mode, press the
RESET
key to reset the current value and the output is also reset.
